Feeder：
1. Pre-stack paper and non-stop feeding device.
2. Printing machine special feeder head.
3. Die- cutting special pull regulation equipped with the French servo take place systems.
Powder-removing section:
1. Electric heating powder removing roller (using φ200mm chrome roll).
2. Laminated glue roller.
3. Pneumatic reversal, traverse moving blade.
Laminating section：
1. Oven drying equipment (drying roll adopting φ810mm water-temperature drying roll), the pneumatic-type front and back unfold the drying cover with 27 pcs stainless steel heat-sinks twining-type heating pipe.
2. Coating systems(ceramic anilox usingφ150mm).
3. Laminating system (mirror roll using φ360mm, pressure glue rollφ280mm, with imported Italian hydraulic system).
Cutter：
1. Toothed knife off film device.
2. Magnetic tension control system.
3. Two sets automatic high-speed rotating disc knife.
4. Pneumatic lift-type laminated pull off devices.
* Optional:
Can be equipped with servo-chain knife cutting system (optional), suitable to use PET film.
Delivery section：
1. Import pressure fan suction device.
2. Rushing paper device.
3. Three-sided beat paper automatic delivery.
4. Automatic excluded waste devices.
5. Non-stop delivery devices.
Performance And Charcteristics:
A. Automatic feeder
1. Adopting maintenance-free of high-speed feeder, high-speed feed stable.
2. Automatic servo take place system, take place precision.
3. Non-oil dry-type vacuum pump.
4. Precision side pull regulation locate systems.
5. Non-stop pre-stacker mechanism, which can effectively improve work efficiency.
B.Automatic powder removing section
1. Vertically adjust heating, chrome calendering roll.
2. Effectively remove dust of the paper surface.
3. Increase the brightness of the film laminating, saving glue consumption.
C. Laminating main motor
1. Placed outside the hot oil circulation heating systems, temperature uniformity.
2. Mirror grinding roller to ensure brightness of coating products.
3. A wide range of temperature settings range up to 180 degrees.
4. Adapt to a variety of film: no-glue film, thermal film.
D.Coating system
1. Ceramic anilox coating, to ensure the glue thinner and more uniformity, can effectively reduce the amount of glue, cost savings.
2. Parallel moving blade, quick and easy to adjust.
3. Suitable for water-based glue and oil-based glue.
E. Drying system
1. Vertical short distance oven design.
2. Fast drying, the film is not shifted.
3. Hot air circulation design, heating up fast.
4. Thermal cycling recycling, saving power consumption.
5. With roll drying, the film is not deformed.
F. Automatic cutter
1. Double knife cutting, cutting more accurate.
2. Electrical adjustable knife location, easy to operate.
3. Multiple sets laminated rolls, fix pull off wheel set.
4. Can be equipped with servo chain knife cutting system (optional).
G. Cold water to eliminate curl system
1. Chrome cold water roller connect outside placed the chiller, can effectively eliminate tissue curl deformation.
H. Automatic delivery
1. Non-stop delivery paper mechanism, greater efficiency.
2. With upper and lower blowing wind mechanism, delivery paper more orderly.
3. Automatic waste discharge, reduce unplanned downtime and improve efficiency.
4. Three-sided beat paper.
