Auto Feeder:
Auto non-stop Feeder: The machine is equipped with a paper pre-stacker, Servo controlled feeder , a photoelectric sensor and double tension control to ensure that paper is continuously fed into the machine.
Man-machine Interface System
color touch screen simplifies the machine operation. On the touch screen, as long as the operator inputs paper size, overlap length etc., the machine can realize completely automated operation. And on touch screen, working status of the machine can be checked at any time.
Side Lay Regulator
The overlap errors are not larger than 2mm due to adopt servo technology controlled by Side Lay Regulator
Power Dusting Device
Optional configuration: Power dusting device adopts heating roller with scraper effectively clean the power and dust in the surface of paper. Improve the brightness and bond after laminating.
Electromagnetic Heater
Equipped with advanced electromagnetic heater which shorten heat up time to 90 seconds, with accurate temperature control:±2℃.
High Speed Separating systerm
Equipped with knife disc, pneumatic perforating device and a photo electrical detector to separate the paper according to paper size quickly.
Chain-knife Cutting Device
Optional configuration: chain-knife cutting, suitable for OPP、PET film and other kinds of film laminating
Pressure Wave Device
With pressure wave structure device collect thin sheet rapidly and successfully.
Anti-curvature device
When going though the anti-curvature device, make crimp productions turn smooth.
High Speed Automatic Stacker
The pneumatic stacker receives the paper, keeping them in order,while rapidly non-stop counting every sheet.
